Reassembly Hints and Tips

CAUTION: Before reassembling a T-MAG™ mag drive pump, carefully read the following instructions and special procedures. Failure to do so may result in premature failure of the mag drive pump components or damage to an individual part making assembly impossible.

NOTE: The steps shown in this example represents all five sizes of T-MAG™ mag drive pumps . The steps shown are not necessarily in order of reassembly of the pump.

Tools Required For Pump Reassembly:
• Metric open-end wrench set
• Adjustable wrench
• Strap wrench or soft jaw vise
• Medium flat head screwdriver
• Metric hex wrench set
